Seagate FireCuda 540 1TB M.2 PCIe Gen 5 NVMe SSD/Solid State Drive
Seagate FireCuda 540 1TB M.2 PCIe Gen 5 NVMe SSD/Solid State Drive
Scan code: LN138316 Manufacturer code: ZP1000GM3A004
£139.99Item currently awaiting an ETA
Pre Order
Pre order

Seagate FireCuda 540 1TB M.2 PCIe Gen 5 NVMe SSD/Solid State Drive

1TB Seagate FireCuda 540, M.2 (2280) PCIe 5.0 (x4) NVMe SSD, 3D TLC, 9500MB/s Read, 8500MB/s, 1.3M /1.5M IOPS, PC/PS5
MORE INFO
MORE INFO

Scan code: LN138316 Manufacturer code: ZP1000GM3A004
£139.99
£5.48 Next day delivery
Item currently awaiting an ETA
Pre Order
Pre order

Email me when the availability or price changes

  • By DPD Have your parcel delivered by DPD to your specified address. Receive SMS with one-hour delivery window | £5.48 Receive SMS with one-hour delivery window Weekend, timed and European delivery options are available at checkout
  • Collect instore Order online, collect from our Bolton store (25-28 Enterprise Park, Middlebrook, Horwich, Bolton, BL6 6PE) | Free
  • UPS and DPD Pickup Pickup from local convenience store | £4.99 Collect your parcel from your newsagents, petrol stations and convenience stores

Finance this product

  • Spend over £280.00 and Buy Now, Pay Later or spread the cost of your finance over 24-48 months with a 10% deposit.
  • SCANPROTECT Protect against installation damage for 28 days.

Suggested Alternatives

Product Overview

Waste No Time

Performance has a new name - FireCuda 540 SSD. With speeds up to 9,500 MB/s, this PCIe Gen5 takes no-prisoners, toppling Gen4 speeds by 50% and going 17 times faster than SATA SSDs. DirectStorage support brings faster load times to games and applications. Plus, handles upwards of 2000 TB total bytes written, perfect for powering through constant abuse. This SSD isn't for the faint of heart.


Ready To Roll

Plug-and-play compatibility with most PCIe Gen5 motherboards and backwards compatible with PCIe Gen4.


Game and Create Like a Pro

DirectStorage support brings faster load times to compatible PC games and applications.


Warranty

Enjoy long-term peace of mind with three years of Rescue Data Recovery Services and a five-year limited warranty.

Features


• Up to 9,00 MB/s brings the full power of PCIe Gen5 speeds to you.5
• 50% faster than PCIe Gen4 SSDs and up to 17× faster than SATA SSDs.
• Seagate-validated E26 controller and the latest 3D TLC SSD NAND.
• Up to 2,000 TB TBW - rewrite up to 1 TB of data every day, for five years (based on 2 TB capacity).


Specifications
Capacity 1TB
Edition FireCuda 540
Form Factor M.2 (2280)
Height 3.6 mm
Interface PCIe 5.0 (x4)
Host Controller Interface NVMe 2.0
Controller
Flash Memory Type TLC 3D NAND
Max. Read 9500 MB/s
Max. Write 8500 MB/s
DRAM Cache Memory N/A
DRAM Cache Memory Type
Max. Random Read 4K 1,300,000 IOPS
Max. Random Write 4K 1,500,000 IOPS
Latency N/A
Special Features
  • Halogen-Free
  • RoHS Compliant
  • S.M.A.R.T Support
  • TCG/Opal V2.0
  • TRIM Support
Power Consumption (active) 10W
Max. Endurance Rating 1000TBW
MTBF 1,800,000 Hours
Max. Operating Vibration
Max. Non-operating Vibration
Max. Operating Shock
Max. Non-operating Shock 1500G
Connectivity 1 x M.2 (PCIe)
OS Support
  • Linux
  • Windows 10
Bracket N/A
Dimensions 22.15 x 3.58 x 80.15 mm (WxHxD)
Weight 7.4 g
Package Type Retail
Additional Information
Scan Code LN138316
Model Number ZP1000GM3A004
GTIN 8719706430876
